Specifications

• Range Of Product: Zelio Logic
• Product Or Component Type: compact smart relay

Contractual warranty

• Warranty: 18 months

Complementary

• Contacts Type And Composition: NO relay output
• Input Impedance: 350 kOhm discrete input
• Discrete Input Frequency: 57…63 Hz || 47…53 Hz
• Number Of Outputs: 4 relay
• Output Thermal Current: 8 A for all 4 outputs relay output
• Discrete Input Voltage: 100…240 V AC
• Number Or Control Scheme Lines: 0-240 ladder || 0-500 FBD
• Backup Time: 10 years 25 C
• Clock Drift: 12 min/year 0-55 C || 6 s/month 25-25 C
• Power Consumption In Va: 7 VA without extension
• Discrete Input Current: 0.6 mA
• Current State 1 Guaranteed: >= 0.17 mA discrete input)
• Response Time: 50 ms ladder from state 0 to state 1)discrete input || 50 ms ladder from state 1 to state 0)discrete input || 50…255 ms FBD from state 0 to state 1)discrete input || 50…255 ms FBD from state 1 to state 0)discrete input || 10 ms from state 0 to state 1)relay output || 5 ms from state 1 to state 0)relay output
• Clock: with
• Local Display: without
• Net Weight: 0.22 kg
• [Uimp] Rated Impulse Withstand Voltage: 4 kV EN/IEC 60947-1 and EN/IEC 60664-1
• Voltage State 0 Guaranteed: <= 40 V discrete input
• Output Voltage Limits: 5…30 V DC relay output) || 24…250 V AC
• Electrical Durability: AC-12 500000 cycles 230 V, 1.5 A relay output EN/IEC 60947-5-1 || AC-15 500000 cycles 230 V, 0.9 A relay output EN/IEC 60947-5-1 || DC-12 500000 cycles 24 V, 1.5 A relay output EN/IEC 60947-5-1 || DC-13 500000 cycles 24 V, 0.6 A relay output EN/IEC 60947-5-1
• Connections – Terminals: screw terminals, 1 x 0.2…1 x 2.5 mm AWG 25…AWG 14) semi-solid || screw terminals, 1 x 0.2…1 x 2.5 mm AWG 25…AWG 14) solid || screw terminals, 1 x 0.25…1 x 2.5 mm AWG 24…AWG 14) flexible with cable end || screw terminals, 2 x 0.2…2 x 1.5 mm AWG 24…AWG 16) solid || screw terminals, 2 x 0.25…2 x 0.75 mm AWG 24…AWG 18) flexible with cable end
• Analogue Input Number: 0
• Voltage State 1 Guaranteed: >= 79 V discrete input
• Current State 0 Guaranteed: <= 0.5 mA discrete input)
• Supply Voltage Limits: 85-264 V
• Overvoltage Category: III EN/IEC 60664-1
• Mechanical Durability: 10000000 cycles relay output
• Maximum Supply Current: 30 mA 240 V without extension) || 80 mA 100 V without extension)
• Tightening Torque: 0.5 N.m
• Isolation Voltage: 1780 V
• Switching Capacity In Ma: >= 10 mA 12 V relay output)
• Protection Type: against inversion of terminals (control instructions not executed)
• Operating Rate In Hz: 0.1 Hz at Ie)relay output || 10 Hz no load)relay output
• Discrete Input Number: 8
• Cycle Time: 6-90 ms
• Supply Frequency: 50/60 Hz
• [Us] Rated Supply Voltage: 100…240 V AC
• Checks: program memory on each power up

Offer Sustainability

• Rohs Exemption Information: Yes
• Mercury Free: Yes
• Environmental Disclosure: ENVPEP060406EN
• Sustainable Offer Status: Green Premium product
• Pvc Free: Yes
• Reach Regulation: Reference contains Substances of Very High Concern above the threshold
• California Proposition 65: WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
• Weee: The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
• China Rohs Regulation: X
• Circularity Profile: ENVEOLI0604006EN
• Eu Rohs Directive: Pro-active compliance (Product out of EU RoHS legal scope)

Environment

• Product Certifications: GOST || C-tick || UL || CSA || GL
• Standards: EN/IEC 60068-2-6 Fc || EN/IEC 61000-4-11 || EN/IEC 61000-4-4 level 3 || EN/IEC 61000-4-2 level 3 || EN/IEC 61000-4-12 || EN/IEC 61000-4-6 level 3 || EN/IEC 61000-4-5 || EN/IEC 60068-2-27 Ea || EN/IEC 61000-4-3
• Disturbance Radiated/Conducted: class B EN 55022-11 group 1
• Ambient Air Temperature For Operation: -20-40 C in non-ventilated enclosure IEC 60068-2-1 and IEC 60068-2-2 || -20-55 C IEC 60068-2-1 and IEC 60068-2-2
• Immunity To Microbreaks: 10 ms
• Environmental Characteristic: EMC directive EN/IEC 61000-6-2 || EMC directive EN/IEC 61000-6-3 || EMC directive EN/IEC 61000-6-4 || EMC directive EN/IEC 61131-2 zone B || low voltage directive EN/IEC 61131-2
• Ip Degree Of Protection: IP20 IEC 60529 terminal block) || IP40 IEC 60529 front panel)
• Pollution Degree: 2 EN/IEC 61131-2
• Ambient Air Temperature For Storage: -40-70 C
• Relative Humidity: 95-95 % without condensation or dripping water
• Maximum Altitude Transport: 3048 m
• Operating Altitude: 6561.68 ft (2000 m)
