Name: Electric Water Spray Kit 02
SKU: ART-A928DB
Availability: InStock

description
information

Documentation

3D Model

Overview

The Electric Water Spray Kit 02 contains all the non-3D printed hardware components necessary to assemble the TEC-9 / T-15 Electric Water Toy Gun. The electric water gun mechanism allows for continuous shooting, with a pulsing water flow activated by pulling the trigger. The mechanism features a simulated recoil function for added fun. To complete the project, you need to download the model files for TEC-9 / T-15 water toy gun on MakerWorld and 3D print the parts.

In the Box

Item Number	Item Name	Quantity
1	Water Sprayer Gearbox Module – S05	1
2	18650 3.7V 2600mAh Li-ion Battery	1
3	USB Charger for 3.7V 18650 Battery with PH2.0 Connector	1
4	BT2.6 Socket Head Cap Self Tapping Screw	2
5	OD24 x 2.5mm O Rings	2
6	3x5mm Transparent Silicone Tube 40cm	1

Difference between Electric Water Spray Kit 01 And This Kit

Product	Electric Water Spray Kit 01	Electric Water Spray Kit 02
Size	5.3 x 2.95 x 20.5 CM	3.27 x 2.49 x 15.7 CM
Auto-fill	Yes	No
Voltage	7.4 V	3.7 V
Range	10 M	7-8 M
Rate of Fire	2 round/s	8 round/s
Silicone tube & screw	Purchased separately 3x5mm Transparent 2m (1PCS)	Inclued

Product Specification

Color	White	Current	0.9 A
Material	Metal and plastic	Voltage	3.7 V
Range	7-8 m	Packaging Size	10013545 mm
Rate of Fire	8 round/s	Packaging Weight	133.9 g

Considerations

Do not operate the Water Toy Gun without water, it may damage the internal components and render it non-functional.
The mechanism includes a simulated recoil feature, please be cautious of interference between the housing and the recoil slider.
The switch and battery are not waterproof, do not submerge the kit directly in water.
You need a H1.5 hex screwdriver to install the bolt handle.
The silicone tube needs to be cut during installation using a cutter (scissors or a utility knife).
