Name: N20 M3 Threaded Shaft Reduction Gear Motor
SKU: ART-B4D2F3
Availability: InStock

description
information

Documentation

Specification 3D Model Application Instruction

Product Specifications

Product ID	Input	Rated Voltage (V)	Operating Voltage (V)	Lmm Shaft Length	No Load Speed RPM	Torque (G*CM	Rotating Direction	Output Shaft Type
LA005	SH1.0-2P	6V	3V ~ 7V	25	400	370	CW	M3
LA006	SH1.0-2P	6V	3V ~ 7V	45	1000	90	CW	M3
LA007	SH1.0-2P	6V	3V ~ 7V	60	1000	90	CW	M3

Instruction

The N20 Reduction Gear Motor is a low-power reduction motor with a D-shaped output shaft, suitable for applications requiring continuous rotation of objects. This motor offers three speed options, including a low-speed version (150rpm), a medium-speed (400rpm), and a high-speed (1000rpm). The motor can be connected to the Power Distribution Board (PDB) with 4 Channels using the Wire Pair with SH1.0-2PIN-5CM/10CM/20CM.

In the box

Item

Qty

N20 M3 Threaded Shaft Reduction Gear Motor

Wire Pair with SH1.0

Considerations

Please use a power supply within the working voltage range.
Avoid immersing the motor in water or getting the motor wet.
Use screws of the appropriate length to secure the gearbox to prevent thread slippage or damage to the gearbox from screws touching the gears.
When using glue/adhesive to fix the motor, to prevent damage, do not let the glue/adhesive seep into the gearbox, shaft, or motor interior.
Regularly add a small amount of lubricant/grease to the gearbox to improve its lifespan and reduce noise.
