Specifications

• Discrete Output Type: solid state
• Range Of Product: Modicon STB distributed I/O solution
• Discrete Output Voltage Type: DC
• Product Or Component Type: standard digital output kit
• Discrete Output Voltage: 24 V
• Discrete Output Number: 6
• Kit Composition: STBXBA1000 base || STBDDO3600 module || STBXTS2100, 6-terminal spring clamp connector || STBXTS1100, 6-terminal screw type connector

Contractual warranty

• Warranty: 18 months

Complementary

• Insulation Between Channels And Logic Bus: 1500 V for 1 minute
• Cold Swapping: yes
• Height: 13.9 mm
• Reset: manual reset COM fault
• Absolute Maximum Voltage: 56 V 1.3 ms
• Discrete Output Logic: positive or negative
• Status Led: 1 LED (Green) module status (RDY) || 1 LED per channel (Green) channel status (OUT1 to OUT6) || 1 LED (Red) module error (ERR)
• Output Voltage: 19.2…30 V DC
• Hot Swapping Fallback: yes for standard NIMs
• Maximum Load Inductance: 500 mH 4 Hz
• Supply: power distribution module
• Response Time: 715 s off-to-on || 955 s on-to-off
• Protection Type: power protection integrated fuse on PDM time lag 10 A || reverse polarity protection || short-circuit protection || thermal overload protection
• Surge Current: 5 A 0.5 ms
• Current Consumption: 90 mA 5 V DC logic bus
• Marking: CE
• Net Weight: 0.114 kg
• Discrete Output Current: 500 mA
• Fallback Status: state 0 basic NIMs || user configurable standard NIMs
• Minimum Load: 0.5 mA
• Width: 128.3 mm
• Overvoltage Category: II
• Depth: 70 mm
• Product Compatibility: power distribution module STBPDT3100/3105 || I/O base STBXBA1000
• Maximum Leakage Current: 0.4 mA at state 0 30 V
• [Us] Rated Supply Voltage: 24 V DC
• Maximum Load Capacitance: 50 F

Offer Sustainability

• Rohs Exemption Information: Yes
• Mercury Free: Yes
• Environmental Disclosure: ENVPEP1511012EN
• Sustainable Offer Status: Green Premium product
• Reach Regulation: Reference contains Substances of Very High Concern above the threshold
• California Proposition 65: WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
• Weee: The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
• China Rohs Regulation: X
• Circularity Profile: ENVEOLI1511012EN
• Eu Rohs Directive: Pro-active compliance (Product out of EU RoHS legal scope)

Environment

• Product Certifications: CSA || UL || FM Class 1 Division 2
• Ambient Air Temperature For Storage: -40…185 F without derating
• Standards: EN/IEC 61131-2
• Ambient Air Temperature For Operation: 0-60 C without derating)
• Shock Resistance: 30 gn 11 ms IEC 88 reference 2-27
• Vibration Resistance: 3 gn 58-150 Hz 35 x 7.5 mm symmetrical DIN rail || 5 gn 58-150 Hz 35 x 15 mm symmetrical DIN rail || +/-0.35 mm 10-58 Hz
• Ip Degree Of Protection: IP20 conforming to EN 61131-2 class 1
• Pollution Degree: 2 IEC 60664-1
• Ambient Air Temperature For Storage: -40-85 C without derating
• Relative Humidity: 95-95 % 60-60 C without condensation
• Operating Altitude: <= 6561.68 ft (2000 m)
• Ambient Air Temperature For Operation: 32…140 F without derating
